Microporous Thermal Insulation Products | WI-MPI-198

Microporous Thermal Insulation Products – Microporous thermal insulation panel engineered by Wedge Insulation for demanding thermal, fire protection, and energy efficiency requirements.

Microporous Thermal Insulation Products Technical Specifications

• Thermal Conductivity: 0.019 – 0.025 W/mK at 200°C

• Max Service Temperature: 900°C – 1200°C

• Density: 200 – 350 kg/m³

• Compressive Strength: 0.3 – 0.8 MPa

• Standard Size: 1000 × 600 mm

Key Benefits

✔ Lowest thermal conductivity of any rigid board insulation
✔ Reduces insulation thickness by up to 75% vs conventional materials
✔ Exceptional performance at elevated temperatures
✔ Rigid and self-supporting — no additional casing required
✔ Non-combustible — Class A fire rating
✔ Ideal for space-critical high-temperature applications

Industries Served

• Industrial Furnaces and Kilns

• Steel and Aluminium Processing

• Fire Protection — Lift and Fire Doors

• Power Generation Equipment

• Aerospace and Defence

• High-Temperature Process Equipment

Grade Options:
Standard / Hydrophobic / High-strength

Thickness Range:
10 mm – 50 mm

Form:
Rigid board / Flexible blanket / Custom fabricated

Supply:
Global supply — India, UK, Europe, Middle East, USA, Asia
